Model:ZN1000C

Concrete Block Making Machine is an automatic block making machine, designed in Germany, made in China. There are 2x7.5kw SIEMENS frequency vibration motors in the bottom，2x0.55KW vibrators on top vibration, can achieve 100KN vibration force. The product height is ranging from 40mm to 300mm.

The Concrete Block Making Machine is a brick-making equipment that specializes in the production of concrete products. Different models of block forming machines are selected according to the output. According to the investment scale, you can choose simple type, optimized type, selected type, semi-automatic configuration, fully automatic configuration, etc. Block forming machine-made brick production line. The feeding system sends concrete raw materials into the mixing system through a conveyor belt. The hopper in the mixing system will mix cement, sand and other raw materials, and add an appropriate amount of water to stir the raw materials evenly. The forming system places the uniformly mixed concrete raw materials into the forming machine, which has different molds to produce concrete blocks of different shapes and sizes. The concrete block forming machine is simple to operate, has high production efficiency, and the quality of the concrete blocks produced is stable.

Product Features

German Design - Higher Efficiency & Lower Failure Rate;
Made in China - Lower Cost & Better service.

ZN1000C block machine adopts German technology, the leading technology for block machine in the world. German technology is known for its rigor and simplicity, paying more attention to the overall performance, efficiency, and machine quality.

ZN1000C block machines are produced in China, strictly accordingly to German technology and craftsmanship. Compared with other brand of block machines, ZN1000C machines have more stable performance, higher production efficiency and lower failure rate. In terms of performance, efficiency, energy-saving, environmental protection, etc., it is far ahead of other block machines in the market.

Technical Parameters

Forming Area	1100×820mm
Height of Finished	50-300mm
Cycle Time	15-25S (as per mould)
Vibration Force	80KN
Pallet Size	1200x870x（12-45）mm
Production per Mold	390x190x190mm（10pcs/mold）
Bottom Vibration	2x7.5KW（SIEMENS）
Top Vibration	2x0.55KW
Electrical Control	SIEMENS
Power	42.25KW
Total Weight	8T（Without Facemix） 11T（With Facemix）
Dimension	6145x2650x3040mm

Technology Advantage

SIEMENS Frequency Vibration Technology

QGM SIEMENS frequency conversional technology was re-innovated and improved by Germany R&D center. The block making vibration adopts low frequency standby, high frequency operation, which improve the running speed and product quality. At the same time, it reduces the impact on the mechanical parts and motor, prolongs the machine and motor lifespan, saving about 20%-30% of electricity when compared with the traditional motor.

SIEMENS Intelligent Control System

QGM control system adopts SIEMENS PLC, Touch Screen, contactors & buttons etc., which perfectly combine the automatic technology and advanced system from Germany. SIEMENS PLC has automatic trouble-shooting function for easy maintenance & also automatic-locking to avoid mechanical accidents caused by operational mistakes. While the SIEMENS touch screen can display real-time production status & achieve easy operation by visualization representation. In case any part is broken in the future, the replacement part can be sourced locally, which can save a lot of time & cost.

Double Vibration System

Vibration table adopts high-duty Sweden HARDOX steel, consisting of dynamic table & static table, which can greatly improve the vibration efficiency. While there are another two vibrators on top, to increase compaction & guarantee the high quality of concrete blocks.

Intelligent Cloud System for Remote Control

QGM intelligent equipment cloud system realizes online monitoring, remote upgrade, remote fault prediction and fault self-diagnosis, equipment health status evaluation, with the advantages of remote control & operation, quick troubleshooting & maintenance for the clients. Everything is interconnected, and the production and operation of equipment can be seen through the network in every corner of the world.

High-Efficient Hydraulic System

The hydraulic motor is SIEEMSN brand, valves are Italy-brand & the hydraulic pipes are Italy-made ALFAGOMMA. Adopt double high-dynamic proportional valve and constant output pump, which can adjust the oil flow and pressure automatically, with the features of high-stability, high-efficiency and energy-saving.
