Cement Block Machine

Model:QT6

As a professional Block Making Machine manufacturer, you can rest assured to buy product from our factory and QGM Block Machine will offer you the best after-sale service and timely delivery. Cement block machine (also known as cement brick machine, brick machine, block machine, briquetting machine, etc.) is a mechanical equipment used to produce quartz sand, cement, ash and other materials mixed and pressed into various specifications. Bricks or blocks.

Send Inquiry

Product Description

Cement Block Machine is an economical & small cement block making machine, independently developed & manufactured by QGM for more than 20 years. It is a matured & cost-effective block making machine, widely praised by customers all over the world & suitable for starting concrete block making business. The cement block machine is easy to operate and reliable in performance, and various types of molds can be customized as needed to produce bricks and blocks of various specifications and sizes. The cement block machine can produce automatically, reducing labor costs. The production efficiency of the cement block machine is very high. The cement block machine has high production accuracy and ensures consistent brick specifications.

Product Features

QT6 is an economical & small concrete block making machine, which can meet the diversified production needs of small enterprises and also cost-effective. It can produce various concrete blocks, such as exterior wall building blocks, interior wall blocks, flower wall bricks, floor slabs, river protection blocks, interlocks and curbstones. The secondary topping system can also produce color pavers.

QT6 machine body is made of high-strength castings and welding of special materials, with good rigidity, vibration resistance and long lifespan. The electrical system adopts German SIEMENS touch screen and programmable logic controller (PLC), including safety logic control and fault diagnosis system. Hydraulic components use high dynamic proportional valves, which can adjust oil volume and pressure according to different production requirements. The four-bar guide mode ensures the precise operation of the tamper head and mold. Using table vibration compaction forming. 360°compulsory feeding, short forming cycle and reach high production efficiency.

Technical Parameters

Cycle Time	15-25S
Motor Total Power	33KW
Motor Frequency	50HZ
Vibration Force	60KN
Total Weight	7.5T
Machine Size	5210×3530×2780mm
Production per Mould	(390x190x190mm) 6pcs/mould
	(240x115x53mm) 30 pcs/mould
	(200x100x60mm) 21 pcs/mould
Pallet Size	850x680mm
Production per shift	(390190190mm) 8,640-11,520pcs
Production per shift	(20010060/80mm) 30,240-40,320pcs

Technology Advantage

Germany SIEMENS Control System

QGM control system adopts SIEMENS PLC, Touch Screen, contactors & buttons etc., which perfectly combine the automatic technology and advanced system from Germany. SIEMENS PLC has automatic trouble-shooting function for easy maintenance & also automatic-locking to avoid mechanical accidents caused by operational mistakes. While the SIEMENS touch screen can display real-time production status & achieve easy operation by visualization representation. In case any part is broken in the future, the replacement part can be sourced locally, which can save a lot of time & cost.

Germany SIEMENS Frequency Vibration Technology

QGM SIEMENS frequency conversional technology was re-innovated and improved by Germany R&D center. The block making vibration adopts low frequency standby, high frequency operation, which improve the running speed and product quality. At the same time, it reduces the impact on the mechanical parts and motor, prolongs the machine and motor lifespan, saving about 20%-30% of electricity when compared with the traditional motor.

Double High-dynamic Proportional Valves

Adopts efficient double high-dynamic proportional Valves, which can automatically adjust the oil flow and pressure and protect the cylinder from damage caused by inertia. Uses integrated high-pressure and soft oil pipes with high quality & also easy for installation.

Compulsory Concrete Feeding System with 360° Multi-Shaft Rotating

It is a speed and rotating concrete feeding system, with uniform mixing, to guarantees density and intensity of concrete products, applicable for different kinds of raw materials and molds;

Intelligent Cloud System for Remote Control

QGM intelligent equipment cloud system realizes online monitoring, remote upgrade, remote fault prediction and fault self-diagnosis, equipment health status evaluation, with the advantages of remote control & operation, quick troubleshooting & maintenance for the clients. Everything is interconnected, and the production and operation of equipment can be seen through the network in every corner of the world.
