Concrete Brick Making Machine

Model:ZN1500C/1800C

Our factory specializes in manufacturing of Block Making Machine. Concrete Brick Making Machine is a device that uses cement concrete as raw material to produce bricks. The concrete brick machine adopts a closed belt conveyor and strictly controls the semi-storage amount of small materials so that they can be delivered and used at any time to prevent the concrete from being liquefied in advance due to the impact of aftershocks and ensure the strength of the Block Machine.

Send Inquiry

Product Description

Concrete Brick Making Machine is a model of European standard machine, which means totally strict accordance with German production technology and craftsmanship and manufactured in China. It integrates various functions and can produce standard concrete products such as paver, curbstone and solid brick on a large scale. The overall structure of the concrete brick machine equipment is compact, the equipment is reasonable, and the rotating parts adopt mechanized devices, which are accurate and reliable. Reduce labor intensity and improve production efficiency. Up and down pressure, directional vibration, and variable frequency braking achieve high-density and high-strength molding effects.

Concrete Brick Making Machine Features

German Design - Higher Efficiency, Lower Failure Rate;
Made in China - Lower Cost, Better service.

ZN1500C/1800C block machine adopts German technology, the leading technology for block machine in the world. German technology is known for its rigor and simplicity, paying more attention to the overall performance, efficiency, and machine quality.

ZN1500C/1800C block machines are produced in China, strictly accordingly to German technology and craftsmanship. Compared with other brand of block machines, ZN1500C/1800C machines have more stable performance, higher production efficiency and lower failure rate. In terms of performance, efficiency, energy-saving, environmental protection, etc., it is far ahead of other block machines in the market.

Technical Parameters

Specification	ZN1500C	ZN1800C
Maximum forming area	1300×1050mm	1300×1300mm
Block height	50-500mm	50-500mm
Cycle time	20~25s (Depending on block type)	20~25s (Depending on block type)
Vibration force	160KN	200KN
Pallet size	1350×1100\1200×(14-50) mm	1400×1400mm
Production per mould	390×190×190mm(15pcs/mould)	390×190×190mm(18pcs/mould)
Bottom vibration	4×7.5KW(SIEMENS)	4×7.5KW(SIEMENS)
Tamper head vibration	2×1.1KW	2×1.1KW
Control system	SIEMENS	SIEMENS
Total power	111.3KW	About 120KW
Total weight	18.3T(without facemix device)	19.5T(without facemix device)
Total weight	25.2T(with facemix device)	27.5T(with facemix device)
Machine size	10920×3250×4485mm	11600×3250×4500 mm

Technology Advantage

Servo vibration system

The machine is equipped with the newly developed servo vibration system, which has a dense and high-excited vibration force, thus ensuring production in an efficient way, especially for large products and high-quality products, which need to be produced by pre-vibration and transitional vibration, can achieve a really nice effect.

Compulsory feeding

The feeding system is applied with the Germany patented design, which is suitable for the use of construction waste and other special aggregates. What’s more, the discharging gate is controlled by SEW motor. The feeding frame, bottom plate & mixing blades are made of high-duty Sweden HARDOX steel, which strengthen the sealing performance and prevent the material leakage to guarantee the long service life, feeding uniform for the improved product quality.

SIEMENS frequency conversional control

SIEMENS Frequency conversional technology was re-innovated and improved by Germany R&D center. The main machine vibration adopts low frequency standby, high frequency operation, which improve the running speed and product quality. At the same time, it reduces the impact on the mechanical parts and the motor, prolongs the life of the machine and the motor, and saves about 20%-30% of electricity compared with the traditional motor operation control.

Fully-automatic control

Perfectly combine the automation technology and system from Germany. The automatic control is of easy operation, low failure ratio and high reliability. At the same time, it has the functions of product formula management and operation data collection.

High-efficient hydraulic system

The hydraulic pump & valve are from international brand, which adopt high dynamic proportional valve and constant output pump to adjust the speed & pressure, with the features of high-stability, high efficiency and energy-saving.

Intelligent Cloud System

QGM intelligent equipment cloud system realizes online monitoring, remote upgrade, remote fault prediction and fault self-diagnosis, equipment health status evaluation; generates equipment operation and application status reports and other functions; with the advantages of remote control & operation, quick troubleshooting & maintenance for the clients. Everything is interconnected, and the production and operation of equipment can be seen through the network in every corner of the world.

Corollary Equipment

Batcher

Automatic pallet feeder

Moisture sensor

Finger car

Block-Pallet separator

Curing chamber

Block-pushing cuber

Customer Case

Wuwei, China

Mengcheng, China

Jiuquan, China
