Vertical Brick Machine Mixer

Vertical Brick Machine Mixer

Model:JS750

As the professional manufacturer, QGM Block Machine would like to provide you Vertical Brick Machine Mixer. And QGM Block Machine will offer you the best after-sale service and timely delivery.A vertical brick machine mixer, also known as a mixer machine, is a device used in the brick making process.

Vertical Brick Machine Mixer is mainly used to mix raw materials like sand, cement, water, and different additives like fly ash, lime, and gypsum to produce a uniform mix that is then fed into the brick machine for molding.The mixer typically consists of a large drum or container with multiple blades or paddles that rotate to mix the materials thoroughly. Some vertical brick machine mixers also include a control system that allows the operator to adjust mixing time, speed, and other parameters to ensure optimal mixing quality.Vertical brick machine mixers are widely used in the brick making industry, especially for producing bricks made of concrete, clay, or cement. They can also be used to mix other materials for construction purposes or in other industries that require a uniform mix of different materials.
Technical Parameters
Item JN350 JS500 JS750 JS1000
Discharging capacity(L) 350 500 750 1000
Feeding capacity(L) 550 750 1150 1500
Theoretic productivity (m³/h) 12.6 25 35 50
Maximum diameter of aggregate ( cobble/crushed stone ) (mm) ≤30 ≤50 ≤60 ≤60
Cycle time (s) 100 72 72 60
Total weight (kg) 3500 4000 5500 8700
Dimensions(mm) Length 3722 4460 5025 10460
Width 1370 3050 3100 3400
Height 3630 2680 5680 9050
Mixing-shaft Rotating Speed(r/min) 106 31 31 26.5
Quantity 1×3 2×7 2×7 2×8
The Power of Mixing Motor(kW) 7.5 18.5 30 2×18.5
The Power of Winding Motor (kW) 4 5.5 7.5 11
The Power of Pump Motor(kW) 1.1 2.2 2.2 3
